Kowa Skymech | Camera Selector

KC48GC4MX

SVGA

Data Download Manual Download Catalogue Download Camera Selector

Model	KC48GC4MX
Monochrome / Color	Mono
Interface	GigE Vision
Sensor Format	1/3"
Resolution	0.48MP 800 (H) x 600 (V)
Pixel Size	5.3um (H) x 5.3um (V)
Shutter	Global Shutter
Frame Rate	87fps
Lens Mount	C-mount
Power Supply	PoE or DC24V
Power Consumption	4.5W max.
Dimension	29.0 (W) x 29.0 (H) x 42.9 (D) mm (not including protrusion parts)
Weight	approx. 70g
Operation Temperature / Humidity	0ºC - +45ºC / 20% - 80% (no condensation)
Storage Temperature / Humidity	-30ºC - +60ºC / 20% - 90% (no condensation)
Vibration	10G (IEC 60060-2-6)
Shock	75G (MIL-STD-810)

KC130GC4MX

1.3MP

Data Download Manual Download Catalogue Download Camera Selector

Model	KC130GC4MX
Monochrome / Color	Mono
Interface	GigE Vision
Sensor Format	1/1.8"
Resolution	1.3MP 1280 (H) x 1024 (V)
Pixel Size	5.3um (H) x 5.3um (V)
Shutter	Global Shutter
Frame Rate	55fps
Lens Mount	C-mount
Power Supply	PoE or DC24V
Power Consumption	4.5W max.
Dimension	29.0 (W) x 29.0 (H) x 42.9 (D) mm (not including protrusion parts)
Weight	approx. 70g
Operation Temperature / Humidity	0ºC - +45ºC / 20% - 80% (no condensation)
Storage Temperature / Humidity	-30ºC - +60ºC / 20% - 90% (no condensation)
Vibration	10G (IEC 60060-2-6)
Shock	75G (MIL-STD-810)

KC500GC4MX

5MP

Data Download Manual Download Catalogue Download Camera Selector

Model	KC500GC4MX
Monochrome / Color	Mono
Interface	GigE Vision
Sensor Format	2/3"
Resolution	5MP 2448 (H) x 2048 (V)
Pixel Size	3.45um (H) x 3.45um (V)
Shutter	Global Shutter
Frame Rate	23fps
Lens Mount	C-mount
Power Supply	PoE or DC24V
Power Consumption	4.5W max.
Dimension	29.0 (W) x 29.0 (H) x 42.9 (D) mm (not including protrusion parts)
Weight	approx. 70g
Operation Temperature / Humidity	0ºC - +45ºC / 20% - 80% (no condensation)
Storage Temperature / Humidity	-30ºC - +60ºC / 20% - 90% (no condensation)
Vibration	10G (IEC 60060-2-6)
Shock	75G (MIL-STD-810)

KC800GC4MX

8MP

Data Download Manual Download Catalogue Download Camera Selector

Model	KC800GC4MX
Monochrome / Color	Mono
Interface	GigE Vision
Sensor Format	2/3"
Resolution	8MP 2856 (H) x 2848 (V)
Pixel Size	2.74um (H) x 2.74um (V)
Shutter	Global Shutter
Frame Rate	13fps
Lens Mount	C-mount
Power Supply	PoE or DC24V
Power Consumption	6.0W max.
Dimension	29.0 (W) x 29.0 (H) x 42.9 (D) mm (not including protrusion parts)
Weight	approx. 70g
Operation Temperature / Humidity	0ºC - +45ºC / 20% - 80% (no condensation)
Storage Temperature / Humidity	-30ºC - +60ºC / 20% - 90% (no condensation)
Vibration	10G (IEC 60060-2-6)
Shock	75G (MIL-STD-810)

KC48GC3MX

SVGA

Data Download Manual Download Catalogue Download Camera Selector

Model	KC48GC3MX
Monochrome / Color	Mono
Interface	GigE Vision
Sensor Format	1/3"
Resolution	0.48MP 800 (H) x 600 (V)
Pixel Size	5.3um (H) x 5.3um (V)
Shutter	Global Shutter
Frame Rate	87fps
Lens Mount	C-mount
Power Supply	PoE or DC24V
Power Consumption	2.0W max.
Dimension	45.0 (W) x 45.0 (H) x 30.0 (D) mm (not including protrusion parts)
Weight	approx. 120g
Operation Temperature / Humidity	0˚C - +45˚C / 20% - 80% (no condensation)td>
Storage Temperature / Humidity	-30˚C - +60˚C / 20% - 90% (no condensation)
Vibration	10G (IEC 60060-2-6)
Shock	75G (MIL-STD-810)
Waterproof / Dustproof	IP67
Oil resist	l (Comply with Kowa Stadard)

KC130GC3MX

1.3MP

Data Download Manual Download Catalogue Download Camera Selector

Model	KC130GC3MX
Monochrome / Color	Mono
Interface	GigE Vision
Sensor Format	1/1.8"
Resolution	1.3MP 1280 (H) x 1024 (V)
Pixel Size	5.3um (H) x 5.3um (V)
Shutter	Global Shutter
Frame Rate	55fps
Lens Mount	C-mount
Power Supply	PoE or DC24V
Power Consumption	4.5W max.
Dimension	45.0 (W) x 45.0 (H) x 30.0 (D) mm (not including protrusion parts)
Weight	approx. 120g
Operation Temperature / Humidity	0˚C - +45˚C / 20% - 80% (no condensation)
Storage Temperature / Humidity	-30˚C - +60˚C / 20% - 90% (no condensation)
Vibration	10G (IEC 60060-2-6)
Shock	75G (MIL-STD-810)
Waterproof / Dustproof	IP67
Oil resist	l (Comply with Kowa Stadard)

KC500GC3MX

5MP

Data Download Manual Download Catalogue Download Camera Selector

Model	KC500GC3MX
Monochrome / Color	Mono
Interface	GigE Vision
Sensor Format	2/3"
Resolution	5MP 2448 (H) x 2048 (V)
Pixel Size	3.45um (H) x 3.45um (V)
Shutter	Global Shutter
Frame Rate	23fps
Lens Mount	C-mount
Power Supply	PoCXP
Power Consumption	3.6W max.
Dimension	45.0 (W) x 45.0 (H) x 30.0 (D) mm (not including protrusion parts)
Weight	approx. 120g
Operation Temperature / Humidity	0˚C - +45˚C / 20% - 80% (no condensation)
Storage Temperature / Humidity	-30˚C - +60˚C / 20% - 90% (no condensation)
Vibration	10G (IEC 60060-2-6)
Shock	75G (MIL-STD-810)
Waterproof / Dustproof	IP67
Oil resist	l (Comply with Kowa Stadard)

KC800GC3MX

8MP

Data Download Manual Download Catalogue Download Camera Selector

Model	KC800GC3MX
Monochrome / Color	Mono
Interface	GigE Vision
Sensor Format	2/3"
Resolution	8MP 2856 (H) x 2848 (V)
Pixel Size	2.74um (H) x 2.74um (V)
Shutter	Global Shutter
Frame Rate	13fps
Lens Mount	C-mount
Power Supply	PoCXP
Power Consumption	6.0W max.
Dimension	45.0 (W) x 45.0 (H) x 40.0 (D) mm (not including protrusion parts)
Weight	approx. 140g
Operation Temperature / Humidity	0˚C - +45˚C / 20% - 80% (no condensation)
Storage Temperature / Humidity	-30˚C - +60˚C / 20% - 90% (no condensation)
Vibration	10G (IEC 60060-2-6)
Shock	75G (MIL-STD-810)
Waterproof / Dustproof	IP67
Oil resist	l (Comply with Kowa Stadard)

KC2400GC3MX

24MP

Data Download Manual Download Catalogue Download Camera Selector

Model	KC2400GC3MX
Monochrome / Color	Mono
Interface	GigE Vision
Sensor Format	1.2"
Resolution	24MP 5328 (H) x 4608 (V)
Pixel Size	2.74um (H) x 2.74um (V)
Shutter	Global Shutter
Frame Rate	4fps
Lens Mount	C-mount
Power Supply	PoCXP
Power Consumption	6.0W max.
Dimension	45.0 (W) x 45.0 (H) x 40.0 (D) mm (not including protrusion parts)
Weight	approx. 140g
Operation Temperature / Humidity	0˚C - +45˚C / 20% - 80% (no condensation)
Storage Temperature / Humidity	-30˚C - +60˚C / 20% - 90% (no condensation)
Vibration	10G (IEC 60060-2-6)
Shock	75G (MIL-STD-810)
Waterproof / Dustproof	IP67
Oil resist	l (Comply with Kowa Stadard)

KC130GC4CX

1.3MP

Data Download Manual Download Catalogue Download Camera Selector

Model	KC130GC4CX
Monochrome / Color	Color
Interface	GigE Vision
Sensor Format	1/1.8"
Resolution	1.3MP 1280 (H) x 1024 (V)
Pixel Size	5.3um (H) x 5.3um (V)
Shutter	Global Shutter
Frame Rate	55fps
Lens Mount	C-mount
Power Supply	PoE or DC24V
Power Consumption	4.5W max.
Dimension	29.0 (W) x 29.0 (H) x 42.9 (D) mm (not including protrusion parts)
Weight	approx. 70g
Operation Temperature / Humidity	0ºC - +45ºC / 20% - 80% (no condensation)
Storage Temperature / Humidity	-30ºC - +60ºC / 20% - 90% (no condensation)
Vibration	10G (IEC 60060-2-6)
Shock	75G (MIL-STD-810)

KC500GC4CX

5MP

Data Download Manual Download Catalogue Download Camera Selector

Model	KC500GC4CX
Monochrome / Color	Color
Interface	GigE Vision
Sensor Format	2/3"
Resolution	5MP 2448 (H) x 2048 (V)
Pixel Size	3.45um (H) x 3.45um (V)
Shutter	Global Shutter
Frame Rate	23fps
Lens Mount	C-mount
Power Supply	PoE or DC24V
Power Consumption	4.5W max.
Dimension	29.0 (W) x 29.0 (H) x 42.9 (D) mm (not including protrusion parts)
Weight	approx. 70g
Operation Temperature / Humidity	0ºC - +45ºC / 20% - 80% (no condensation)
Storage Temperature / Humidity	-30ºC - +60ºC / 20% - 90% (no condensation)
Vibration	10G (IEC 60060-2-6)
Shock	75G (MIL-STD-810)

KC800GC4CX

8MP

Data Download Manual Download Catalogue Download Camera Selector

Model	KC800GC4CX
Monochrome / Color	Color
Interface	GigE Vision
Sensor Format	2/3"
Resolution	8MP 2856 (H) x 2848 (V)
Pixel Size	2.74um (H) x 2.74um (V)
Shutter	Global Shutter
Frame Rate	13fps
Lens Mount	C-mount
Power Supply	PoE or DC24V
Power Consumption	6.0W max.
Dimension	29.0 (W) x 29.0 (H) x 42.9 (D) mm (not including protrusion parts)
Weight	approx. 70g
Operation Temperature / Humidity	0ºC - +45ºC / 20% - 80% (no condensation)
Storage Temperature / Humidity	-30ºC - +60ºC / 20% - 90% (no condensation)
Vibration	10G (IEC 60060-2-6)
Shock	75G (MIL-STD-810)

KC130GC3C

5MP

Data Download Manual Download Catalogue Download Camera Selector

Model	KC130GC3C
Monochrome / Color	Color
Interface	GigE Vision
Sensor Format	1/1.8"
Resolution	1.3MP 1280 (H) x 1024 (V)
Pixel Size	5.3um (H) x 5.3um (V)
Shutter	Global Shutter
Frame Rate	55fps
Lens Mount	C-mount
Power Supply	PoE or DC24V
Power Consumption	4.5W max.
Dimension	45.0 (W) x 45.0 (H) x 30.0 (D) mm (not including protrusion parts)
Weight	approx. 120g
Operation Temperature / Humidity	0˚C - +45˚C / 20% - 80% (no condensation)
Storage Temperature / Humidity	-30˚C - +60˚C / 20% - 90% (no condensation)
Vibration	10G (IEC 60060-2-6)
Shock	75G (MIL-STD-810)
Waterproof / Dustproof	IP67
Oil resist	l (Comply with Kowa Stadard)

KC500GC3CX

8MP

Data Download Manual Download Catalogue Download Camera Selector

Model	KC500GC3CX
Monochrome / Color	Color
Interface	GigE Vision
Sensor Format	2/3"
Resolution	5MP 2448 (H) x 2048 (V)
Pixel Size	3.45um (H) x 3.45um (V)
Shutter	Global Shutter
Frame Rate	23fps
Lens Mount	C-mount
Power Supply	PoE or DC24V
Power Consumption	4.5W max.
Dimension	45.0 (W) x 45.0 (H) x 30.0 (D) mm (not including protrusion parts)
Weight	approx. 140g
Operation Temperature / Humidity	0ºC - +45ºC / 20% - 80% (no condensation)
Storage Temperature / Humidity	-30ºC - +60ºC / 20% - 90% (no condensation)
Vibration	10G (IEC 60060-2-6)
Shock	75G (MIL-STD-810)
Waterproof / Dustproof	IP67
Oil resist	l (Comply with Kowa Stadard)

KC800GC3CX

8MP

Data Download Manual Download Catalogue Download Camera Selector

Model	KC800GC3CX
Monochrome / Color	Color
Interface	GigE Vision
Sensor Format	2/3"
Resolution	8MP 2856 (H) x 2848 (V)
Pixel Size	2.74um (H) x 2.74um (V)
Shutter	Global Shutter
Frame Rate	13fps
Lens Mount	C-mount
Power Supply	PoCXP
Power Consumption	6.0W max.
Dimension	45.0 (W) x 45.0 (H) x 30.0 (D) mm (not including protrusion parts)
Weight	approx. 140g
Operation Temperature / Humidity	0˚C - +45˚C / 20% - 80% (no condensation)
Storage Temperature / Humidity	-30˚C - +60˚C / 20% - 90% (no condensation)
Vibration	10G (IEC 60060-2-6)
Shock	75G (MIL-STD-810)
Waterproof / Dustproof	IP67
Oil resist	l (Comply with Kowa Stadard)

KC2400GC3CX

24MP

Data Download Manual Download Catalogue Download Camera Selector

Model	KC2400GC3CX
Monochrome / Color	Color
Interface	GigE Vision
Sensor Format	1.2"
Resolution	24MP 5328 (H) x 4608 (V)
Pixel Size	2.74um (H) x 2.74um (V)
Shutter	Global Shutter
Frame Rate	4fps
Lens Mount	C-mount
Power Supply	PoCXP
Power Consumption	6.0W max.
Dimension	45.0 (W) x 45.0 (H) x 40.0 (D) mm (not including protrusion parts)
Weight	approx. 140g
Operation Temperature / Humidity	0˚C - +45˚C / 20% - 80% (no condensation)
Storage Temperature / Humidity	-30˚C - +60˚C / 20% - 90% (no condensation)
Vibration	10G (IEC 60060-2-6)
Shock	75G (MIL-STD-810)
Waterproof / Dustproof	IP67
Oil resist	l (Comply with Kowa Stadard)

KC48XS1MX

SVGA

Data Download Manual Download Catalogue Download Camera Selector

Model	KC48XS1MX
Monochrome / Color	Mono
Interface	CXP-2
Sensor Format	1/3.6"
Resolution	0.48MP 800 (H) x 600 (V)
Pixel Size	4.8um (H) x 4.8um (V)
Shutter	Global Shutter
Frame Rate	100fps
Lens Mount	S-mount
Power Supply	PoCXP
Power Consumption	2.0W max.
Dimension	29.0 (W) x 29.0 (H) x 33.0 (D) mm (not including protrusion parts)
Weight	approx. 30g
Operation Temperature / Humidity	0℃～+45℃ / 20%～80% (no condensation, below 55℃ on cabinet surface)
Storage Temperature / Humidity	-30℃～+60℃ / 20%～90% (no condensation)
Vibration	10G (IEC 60060-2-6)
Shock	75G (MIL-STD-810)

KC130XC2MX

1.3MP

Data Download Manual Download Catalogue Download Camera Selector

Model	KC130XC2MX
Monochrome / Color	Mono
Interface	CXP-2
Sensor Format	1/1.8"
Resolution	1.3MP 1280 (H) x 1024 (V)
Pixel Size	5.3um (H) x 5.3um (V)
Shutter	Global Shutter
Frame Rate	55fps
Lens Mount	C-mount
Power Supply	PoCXP
Power Consumption	4.5W max.
Dimension	29.0 (W) x 29.0 (H) x 37.0 (D) mm (not including protrusion parts)
Weight	approx. 50g
Operation Temperature / Humidity	0℃～+45℃ / 20%～80% (no condensation, below 55℃ on cabinet surface)
Storage Temperature / Humidity	30℃～+60℃ / 20%～90% (no condensation)
Vibration	10G (IEC 60060-2-6)
Shock	75G (MIL-STD-810)

KC500XC3MX

5MP

Data Download Manual Download Catalogue Download Camera Selector

Model	KC500XC3MX
Monochrome / Color	Mono
Interface	CXP-6
Sensor Format	2/3"
Resolution	5MP 2464 (H) x 2056 (V)
Pixel Size	3.45um (H) x 3.45um (V)
Shutter	Global Shutter
Frame Rate	95fps
Lens Mount	C-mount
Power Supply	PoCXP
Power Consumption	3.6W max.
Dimension	29.0 (W) x 29.0 (H) x 37.0 (D) mm (not including protrusion parts)
Weight	approx. 50g
Operation Temperature / Humidity	0℃～+45℃ / 20%～80% (no condensation, below 55℃ on cabinet surface)
Storage Temperature / Humidity	-30℃～+60℃ / 20%～90% (no condensation)
Vibration	10G (IEC 60060-2-6)
Shock	75G (MIL-STD-810)

KC130XC2CX

1.3MP

Data Download Manual Download Catalogue Download Camera Selector

Model	KC130XC2CX
Monochrome / Color	Color
Interface	CXP-2
Sensor Format	1/1.8"
Resolution	1.3MP 1280 (H) x 1024 (V)
Pixel Size	5.3um (H) x 5.3um (V)
Shutter	Global Shutter
Frame Rate	55fps
Lens Mount	S-mount
Power Supply	PoCXP
Power Consumption	1.5W max.
Dimension	29.0 (W) x 29.0 (H) x 37.0 (D) mm (not including protrusion parts)
Weight	approx. 50g
Operation Temperature / Humidity	0℃～+45℃ / 20%～80% (no condensation, below 55℃ on cabinet surface)
Storage Temperature / Humidity	-30℃～+60℃ / 20%～90% (no condensation)
Vibration	10G (IEC 60060-2-6)
Shock	75G (MIL-STD-810)

KC500XC3CX

5MP

Data Download Manual Download Catalogue Download Camera Selector

Model	KC500XC3CX
Monochrome / Color	Color
Interface	CXP-6
Sensor Format	2/3"
Resolution	5MP 2464 (H) x 2056 (V)
Pixel Size	3.45um (H) x 3.45um (V))
Shutter	Global Shutter
Frame Rate	95fps
Lens Mount	C-mount
Power Supply	PoCXP
Power Consumption	3.6W max.
Dimension	29.0 (W) x 29.0 (H) x 37.0 (D) mm (not including protrusion parts)
Weight	approx. 50g
Operation Temperature / Humidity	0℃～+45℃ / 20%～80% (no condensation, below 55℃ on cabinet surface)
Storage Temperature / Humidity	-30℃～+60℃ / 20%～90% (no condensation)
Vibration	10G (IEC 60060-2-6)
Shock	75G (MIL-STD-810)

KC130GP103

300mm / 400mm

Data Download Manual Download Catalogue Download Camera Selector

Model	KC130GP103
Monochrome / Color	Mono
Interface	GigE Vision
Resolution	1248 x 993 pixel
Depth	300mm / 400mm
Field of View (H x V)	101mm x 112mm / 154mm x 154mm
Speed	50ms max.
Power Supply	PoE
Power Consumption	13W
Dimension	142.0 (W) x 62.5 (H) x 121.0 (D) mm
Weight	approx. 1200g
Operation Temperature	0°C - +45°C (no condensation)
Waterproof / Dustproof	IP67
Vibration	10G
Shock	75G

KC130GP109

8MP

Data Download Manual Download Catalogue Download Camera Selector

Model	KC130GP109
Monochrome / Color	Mono
Interface	GigE Vision
Resolution	1248 x 993 pixel
Depth	600mm / 1500mm
Field of View (H x V)	222mm x 240mm / 702mm x 624mm
Speed	50ms max.
Power Supply	PoE
Power Consumption	13W
Dimension	142.0 (W) x 62.5 (H) x 121.0 (D) mm
Weight	approx. 1200g
Operation Temperature	0°C - +45°C (no condensation)
Waterproof / Dustproof	IP67
Vibration	10G
Shock	75G

KC130GP125

2000mm / 3500mm

Data Download Manual Download Catalogue Download Camera Selector

Model	KC130GP125
Monochrome / Color	Mono
Interface	GigE Vision
Resolution	1248 x 993 pixel
Depth	2000mm / 3500mm
Field of View (H x V)	970mm x 837mm / 1771mm x 1477mm
Speed	50ms max.
Power Supply	PoE
Power Consumption	13W
Dimension	142.0 (W) x 62.5 (H) x 121.0 (D) mm
Weight	approx. 1200g
Operation Temperature	0°C - +45°C (no condensation)
Waterproof / Dustproof	IP67
Vibration	10G
Shock	75G

KC130GP120

24MP

Data Download Manual Download Catalogue Download Camera Selector

Model	KC130GP120
Monochrome / Color	Mono
Interface	GigE Vision
Resolution	1248 x 993 pixel
Depth	1500mm / 3500mm
Field of View (H x V)	1202mm x 960mm / 2961mm x 2279mm
Speed	50ms max.
Power Supply	PoE
Power Consumption	13W
Dimension	142.0 (W) x 62.5 (H) x 121.0 (D) mm
Weight	approx. 1200g
Operation Temperature	0°C - +45°C (no condensation)
Waterproof / Dustproof	IP67
Vibration	10G
Shock	75G

INDUSTRIAL LENS

FIXED FOCAL

LINE SCAN

TELECENTRIC

VARIFOCAL

MACRO ZOOM

ACCESSORIES

2D / 3D Camera

VISION PROCESSOR
